This article helps you in getting an idea to solve the official Maharashtra HSC Class 12 Physics board question paper 2025 for the academic year 2025–2026, as per the latest syllabus and examination pattern.
Date: 17th February 2025
Marks: 80
Time: 3 hours
Maharashtra HSC Class 12 Physics Question Paper 2025
SECTION – A (18 Marks)
Q.1 – Multiple Choice (10 × 1mark each)
Maharashtra HSC Class 12 Physics Board Exam 2025 – Complete Question Paper
Select and write the correct answer:
- “If two systems are each in thermal equilibrium with a third system, they are also in thermal equilibrium with each other.” This statement refers to ______.
- a) Zeroth law of thermodynamics
- b) First law of thermodynamics
- c) Second law of thermodynamics
- d) Carnot’s law
- In Bernoulli’s theorem, which of the following is constant?
- a) Linear momentum
- b) Angular momentum
- c) Mass
- d) Energy
- Which of the following materials belongs to a diathermanous substance?
- a) Wood
- b) Iron
- c) Glass
- d) Copper
- Electric potential ‘V’ at a distance ‘r’ from a point charge is directly proportional to ______.
- a) r
- b) r²
- c) 1/r
- d) 1/r²
- Which of the following expressions gives the correct internal resistance of a cell using a potentiometer?
- a) r = R [V/E – 1]
- b) r = R [1 – E/V]
- c) r = R [1 – V/E]
- d) r = R [E/V – 1]
- An electron, a proton, an α-particle and a hydrogen atom are moving with the same kinetic energy. The associated de Broglie wavelength will be longest for ______.
- a) Electron
- b) Proton
- c) α-particle
- d) Hydrogen atom
- The gate which produces high output only when both its inputs are high is ______.
- a) XOR gate
- b) AND gate
- c) NAND gate
- d) NOR gate
- The power rating of a ceiling fan rotating with a constant torque of 2 Nm and angular speed 2π rad/s will be ______.
- a) π W
- b) 2π W
- c) 3π W
- d) 4π W
- A string of length 2 m is vibrating with 2 loops. The distance between its node and adjacent antinode is ______.
- a) 0.5 m
- b) 1.0 m
- c) 1.5 m
- d) 2.0 m
- A transformer increases an alternating emf from 220 V to 880 V. If the primary coil has 1000 turns, the number of turns in the secondary coil are ______.
- a) 1000
- b) 2000
- c) 3000
- d) 4000
Q.2 – Very Short Answer (8 × 1Mark each)
- At what temperature does the surface tension of a liquid become zero?
- Define self-inductance.
- What is the work done by an external uniform magnetic field perpendicular to the velocity of a moving charge?
- What do you mean by a thermodynamic system?
- What is the value of B when H = 0 in the hysteresis loop?
- State the formula for the angle of banking.
- Calculate the electric field intensity at a point near the surface of a charged plane sheet of charge density σ = 8.85 μC/m².
- Find the kinetic energy of 1 litre of an ideal gas at STP.
SECTION – B (16 Marks)
Attempt any 8 questions(2 Marks each):
- Explain harmonics.
- Explain overtones.
- Using Newton’s law of viscosity for streamline flow, derive an expression for the coefficient of viscosity.
- State the formula for magnetic induction due to current in a circular arc of wire and find the induction at the centre.
- State and prove the Law of Conservation of Angular Momentum.
- State any four advantages of a light emitting diode (LED).
- Calculate the energy radiated in one minute by a perfect black body of surface area 200 cm² at 127 °C.
- Two coils with self-inductance 60 mH each are coupled with coefficient 0.75. Find mutual inductance.
- In a series LCR circuit, R = 3Ω, XL = 8Ω, XC = 4Ω. Calculate phase difference between voltage & current.
- State advantages of potentiometer over voltmeter.
- Draw circuit diagram of a full wave rectifier.
- A body of mass 0.8 kg performs SHM with restoring force 0.4 N at 4 cm. Find force constant and period.
SECTION – C (24 Marks)
Attempt any 8 questions (3 Marks each):
- Obtain expression for the period of a magnet vibrating in a uniform magnetic field performing SHM.
- (i) Define mechanical equilibrium in a thermodynamic system.
(ii) Define chemical equilibrium.
(iii) Define thermal equilibrium. - What is Brewster’s law? Derive formula for Brewster’s angle.
- Derive expression for law of radioactive decay.
- Define one Becquerel.
- (i) Expression for practical determination of end correction for open pipe.
(ii) Same for closed pipe. - A conducting bar rotates with constant angular speed in a uniform magnetic field. Obtain expression for emf induced.
- Number of revolutions made by electron in hydrogen atom staying in second orbit for 10⁻⁸ s.
- A flywheel has mass 100 kg and radius 1.5 m, torque 2000 Nm, starts from rest. Find work done in first 4 revolutions.
- (i) Cylinder resistance problem converting galvanometer to ammeter.
(ii) Same converting to voltmeter. - Diameter of water drop 0.6 mm. Calculate pressure inside drop.
- Solenoid of length π m and diameter 5 cm is wound with 1000 turns carrying 5 A. Find magnetic field at centre.
SECTION – D (12 Marks)
Attempt any 3 questions: (4 Marks each)
- What is ferromagnetism? Explain based on domain theory.
- Obtain expression for average power dissipated in series LCR circuit.
- Distinguish between interference and diffraction of light.
- State Einstein’s photoelectric equation and mention physical significance of each term. Also calculate energy of incident photon (λ = 4000 Å).
- State any four uses of Van de Graaff generator. Also, for a parallel plate air capacitor changing electric field at 2×10¹¹ V/ms with plate area 20 cm², calculate displacement current.
All above questions for class 12 hsc maharashtra students are advised to read all questions carefully and attempt them according to the given instructions using logbook wherever necessary and keep the time management to attempt full 70 marks paper.
